43 Inch Outdoor Portable LCD

43 Inch Outdoor Portable LCD

Quote Now

Structural performance:

a.The shell material is made of fully galvanized steel plate, the outer surface is imported metallic paint, anti-magnetic, anti-static, and imported waterproof materials. The whole machine adopts IP55 waterproof, outdoor all-weather waterproof and dustproof, anti-theft, explosion-proof and other designs.

b.Strict electrical protection: leakage, overload, overvoltage protection, lightning protection device, over temperature protection, etc.

c.Sound: Using a two-channel, stereo surround power amplifier system, the output power is 8 ohms 2×10W.

d.The design standard of the working environment is +110°~-50°, and the cooling adopts a stable and reliable air-cooled structure for heat dissipation and aluminum military-grade heat dissipation substrate.

e.Tempered glass: 6mm AR tempered laminated glass is used.

f.Each system of the whole machine adopts the principle of modular design, and is designed for sustainability and maintainability.

g.The light sensing system is superior: the ambient brightness is automatically adjusted to control anti-glare, which meets the clear image display in the environment of strong direct sunlight.

Product advantage:

a.The high-brightness LED backlit LCD screen has a brightness of 1800nits, and it is still clearly visible in the sunlight environment.

b.The unique wide-temperature processing of the liquid crystal substrate can reach -50℃-110℃, fast start-up and clear image display in a low temperature environment.

c.True, bright and vivid color display, with a resolution of up to 2160 x 3840.

d.Outdoor rainproof and heat-resistant metal housing, as well as to meet the waterproof and dust-proof shell structure in outdoor stormy environments.

e.Built-in stand-alone (network) playback board, industrial computer (optional), interactive multi-touch (optional).



Technical Parameter









Panel parameters

Panel type 43”LED Panel
Display size 943×531mm(W*H)
Display ratio 16:9
Backlight type Patented LED backlight modular assembly + constant current source drive assembly
Resolution 1080*1920
Display color 16.7M
brightness 1800cd/m2 meets the clear image display in the environment of strong direct sunlight
Contrast 3500:1
Viewing angle 178°(H) / 178°(V)
Response time 5ms
Color standard PAL/NTSC/SECAM
Service life 60000hours
Motherboard parameters CPU Cortex-A7,Frequency 1.2G
memory DDR3 1G
Built-in memory Supports up to 32GB TF card expansion
Decoding resolution Support up to 1080P
Operating system Android 7.1.1
Network support 3G/4G Wide area network, Ethernet, support WiFi, wireless peripheral expansion
Video playback Support AVI(H.264、DIVX、DIVX、XVID), rm,rmvb, MKV(H.264、DIVX、DIVX、XVID),WMV,MOV,MP4(.H.264、MPEG、DIVX、XVID),DAT(VCD format),VOB(DVD format),PMP,MPEG,.MPG,, FLV(H.263,H.264),ASF  ,TS, TP,3GP,MPG etc. More than 30 formats.
Image format Support BMP、JPEG、PNG、GIF
USB2.0 interface 2 USB HOST standard interfaces, 2 USB expansion interfaces
System upgrade Support USB upgrade, SD card upgrade, remote upgrade
Battery parameters Battery technology Blade battery, long service time and stable performance
Charging time 7 hours
Working hours 14 hours
Battery capacity 50000 mAh
Input voltage 24V
Working environment Operating temperature -50℃~110℃
Storage temperature -45℃~80℃
Working humidity 10%~90%
Storage humidity 10%~90%
Power input AC100V~240V
Power consumption ≤100W
Standby power consumption ≤3W
Appearance color Silver, gray, white, black, red
Shell material Galvanized steel plate + outdoor special paint
Product certification ISO9001,3C,FCC,UL
Net weight 40Kg
Gross weight 48Kg
Product size 1236mm*148mm*588mm
Package size 1350mm*300mm*700mm
